The Roland BN20 is a 20” print and cut machine that can make anything from full colors stickers and decals to custom t-shirt and more.
And it does that by being both a full color printer AND a standard vinyl cutter.
Giving the BN20 some impressive capabilities I-want-to-start-a-business capabilities.
A printer cutter or print and cut machine looks like a standard vinyl cutter that you might use just for heat transfer vinyl (HTV) or sign vinyl.
Standard vinyl cutters allow you to cut out heat transfers of a single-color material.
For example, you need to put a last name to customize football jersey you might choose a roll of white vinyl to cut out that one color. Then heat press it onto the jersey.
Or you could be creating a multi-color design like the one shown, but each single-color layer is done separately and combined on the shirt. (in the case of HTV)
The good news here is that yes, the Roland BN20 printer cutter will do that as well.
When you look at the BN-20 you can quickly see what sets it apart from a standard vinyl cutter though. Cartridges of ink!
Because the BN-20 is combination of that vinyl cutter AND a full color inkjet printer. You simply load your “cutter” with one of several kinds of printable vinyl instead of standard HTV.
What you can make is really limited only by your imaginations!
One of the most profitable things you can create with the Roland is custom apparel and accessories.
Here are some examples of potential profits buying wholesale blank t-shirts or bags from Colman and Company, decorating them with the BN20 and selling them retail.
Apparel Profit Calculator
|Blank Item Cost||$15.00||$15.00||$2.00||$50.00||$15.00|
|HTMS + Ink Cost||$1.20||$2.40||$0.72||$2.40||$2.40|
|Graphic Size||9" x 5"||9" x 5" (2 sides)||6" x 4.5"||9" x 5" (2 sides)||9" x 5" (2 sides)|
|Pieces per Hour||20||10||30||10||10|
|Profit per Hour||$276.50||$176.00||$248.40||$226.00||$326.00|
Roland VersaWorks RIP software comes with every print-cut machine. It controls everything about the machine, allowing you to efficiently prepare artwork for both print & cut functions with ease.
VersaWorks is a powerful, but simple to use application that works hand in hand with many popular vector graphics applications. Here’s how it works:
You can either create something yourself in applications like CorelDraw, or you can work with a company like ColDesi-Graphics.com to have them created for you. If you’re not a graphic artist, you may want to start ordering custom art first as you develop your own skills.
It’s here that you will choose the kind of media you’re working with, like window film or sticker vinyl, and how many copies of the design you would like to print. You CAN do much more in VersaWorks, but those are the basics.
If you run a retail business where customers can see the BN20 print and cut, this will be a conversation stopper. People love to watch it print!
Or fill out the form below for more info.
|Printing Method / Cutting Method||Piezoelectric inkjet / Grit roller feed|
|Acceptable Media Width||5.9 to 20.3 in. (150 to 515 mm)|
|Acceptable Media Thickness||
Printing: Maximum 39 mil (1.0 mm) with liner
Cutting: Maximum 16 mil (.4 mm) with liner
|Acceptable Media Roll Weight||Maximum 13.2 lbs (6 kg)|
|Acceptable Media Roll Outer Diameter||Maximum 5.9 in (150 mm)|
|Acceptable Media Core Diameter||2 in (50.8 mm)or 3 in (76.2 mm) cores|
|Printing/cutting width||Maximum 18.9 in (480 mm)|
|Ink Cartridges - Type & Capacity||Roland ECO-SOL MAX or FPG Aqueous, 220 ml only|
5 Color – CMYK+Mt (Cyan, Magenta, Yellow, Black and Metallic Silver) or CMYK+Wh (Cyan, Magenta, Yellow, Black, and White)
4 Color - CMMYK (Cyan, Magenta, Yellow, Black)
|Printing Resolution||Max 1440 dpi|
|Cutting Blade Type||Roland CAMM-1 series cutter blade|
|Cutting Force / Offset||30 to 300gf / Fixed Offset|
|Power-saving Function||Automatic sleep feature|
|Power Supply||AC 100 to 240±10 %, 7.2 A, 50/60 Hz|
|Dimensions||39.2 (W) x 23 (D) x 11.5 (H) in (995 (W) x 585 (D) x 291 (H) mm)|
|Weight||77 lbs (35 kg)|
